Universal input voltage
Interchangeable / Folding plug
Short circuit protection
Level VI Efficiency Regulations Compliance
Super Mini Size and Easy Portable
High efficiency & reliability
Outputs are available at request
Constant Current For Battery Charge
Optional output connectors
Three year limited warranty
Input Voltage: 100~240V AC 50~60Hz
Input plug:Interchangeable / Folding plug
Output Voltage:5V3A/9V3A/12V3A/15V3A/20V2.25A/20V4A
Protection: Over voltage protection & Over current protection & Over Temperature protection & Short circuit protection & Reverse polarity protection.
Temperature coefficient: All out+-0.04%℃ maximum
Transient response:Maximum excursion of 4% or better on all models.Recovering to 1% of final value within 500uS after a 25% step load change.
Operating temperature:0℃~+40℃.
Storage temperature:-40℃~+85℃;.
Relative humidity:5% to 95% non-condensing.
Insulation resistance:50Mohm minimum from output to ground.
Withstand voltage:4300VDC from input to output
Mean time between failure:100,000 hours minimum at full load 25℃ ambient
Energy Saving (Level VI / Level 6)
EMC requirements:FCC CLASS B, EN55022 CLASS B.EN 55024: 1998+A1: 2001+A2: 2003; Part 15 Subpart B, IC ICES-003
Safety requirements:UL 60950-1: 2007,EN 55022:55024/EN 60950-1/EN 61558-1/EN 61558-2-16,EN 60950-1/EN 61558-1/EN 61558-2-16/AfPS GS 214,AS/NZS 60950-1:2011& AS/NZS 3112:2011.
Warranty: 3- Years.
